Features and Options
Features
Technical Specifications: Static moment at the turret pin: 22000 (daN/m), 159160 (lbs/ft) Hyd. boom length: 13700 (mm), 44' 11" (in) Length: 910 (940) (mm), 2' 12" (3' 1") (in) Width: 2500 (mm), 8' 2" (in) Height: 2287 (mm), 7' 6" (in) Weight (without oil and fitting): 2960 (kg), 6526 (lbs) Lifting capacity: 8400 (kg), 18519 (lbs) Boom length with manual extensions: 15840 (mm), 51' 12" (in) Slew torque: 2600 (daN/m), 18810 (lbs/ft) Slewing speed: 360 - 40 (° – sec), 360 - 40 (° – sec) Outriggers extension: 1850 + 1600 (mm), 6' 1" + 5' 3" (in) Outriggers width: 5830 (mm), 19' 2" (in) Pump delivery: 45 (lit/min), 11,9 Pressure: 300 (bar), 4270 (Psi) Oil tank capacity: 140 (lit), 37 (us gal)Product Specs
- Location : Kansas City, KS
- Ton-Meters : 22.00
- Ton Rating: 9.25
- Boom (ft) : 44
- Type : Knuckle Boom Cranes
Equipment at Kansas City, KS
Cormach
All Cormach cranes include a column with a twin mast, large dimension slew bearing with external rotation motor, and gearbox. Cormach’s unique design eliminates harmful stress on the boom. The powerful Cormach structure with slew bearing and column is often used by companies needing a large knuckle boom crane; only Cormach uses this heavy duty structure throughout its entire line. This construction provides many advantages when compared with competitors' cranes.
